Model
R-type Hot Water Circulation Pump

Item specifics

Material
cast iron material
Capacity
7.2-1350m3/h
Max Head
10-80m
Colour
customizable

Review

Description

  • Product Introduction
  • Product Features
  • Scope of Application
  • Structural Drawings
  • Performance Parameters
  • Data Download

Product Introduction

The R-type hot water circulation pump is a highly efficient pump specifically designed for hot water circulation systems, suitable for applications such as heating, air conditioning, and hot water supply. This pump can stably convey high-temperature hot water, ensuring the efficient operation of the system.

Model Description:

Example: 65R-40A
65 - The inlet diameter is 65mm.
R - Single-stage single-suction hot water circulating pump.
40 - The designed head at the design point is 40m.
A - Impeller outer diameter cutting code.

Product Features:

  • High efficiency and energy saving: Adopting advanced hydraulic models, it features high efficiency and low energy consumption.
  • High temperature resistance: It can stably convey high-temperature hot water and adapt to various working conditions.
  • Low noise: Optimized design ensures smooth operation and low noise.
  • Easy maintenance: Simple structure, easy to install and maintain.
  • Long service life: Made of high-quality materials, it is resistant to corrosion and wear, with a long service life.

Scope of Application:

- Heating system: for centralized heating and district heating.
- Air conditioning system: for air conditioning water circulation.
- Hot water supply: for hot water circulation in hotels, hospitals and other places.
- Industrial circulation: for high-temperature water circulation in industrial equipment.

Structural Drawings:

Multi-stage pump structure diagram

Performance Parameters:

NO.
Model
Flow
Head
Speed
Efficiency
(NPSH)r
Motor Power
Inlet
Diameter
Outlet
Diameter
m3/h
L/s
m
rpm
%
m
kW
mm
mm
1
40R-26
4.32
7.2
8.64
1.2
2
2.4
26.7
26
25.7
2950
43
57
59
3.0
1.5
40
32
2
50R-25
8.64
14.4
17.28
2.4
4
4.8
26
25
24.2
2950
52
65
68
3.0
2.2
50
50
3
50R-80
7.5
12.5
15
2.08
3.43
4.17
82
80
78
2950
28.5
38
41
2.3
11
50
32
4
65R-64

28.8

8
64
2950
54
4.0
30
65
50
5
80R-60

54

15
60
2950
65
4.0
18.5
80
65
6
100R-57
100.8

28

57
2950
72
6.0
30
100
80
7
150R-56
190.8
53
55.5
1480
68
4.0
55
150

100

8
200R-72A
265
73.61
64
1480
68
6.0
75
200

150

9
250R-62
450
125
62
1480
78
6.0
110
250

200

10
300R-74
1075
298.61
74
1480
85
4.7
200
300

250

11
350R-62
1350
375
62
1480
80
8.0
355
350

300

...
...
...
...
...
...
...
...
...
...
...

*For more models, please download our catalogue or contact us.

Data Download:

Download Multi-stage pumps PDF brochure

R-type HOT Water circulation Pump

Download Product PDF Brochure

PDF Download
